USE OF THE SIDE PROTECTOR SYSTEM
EN
Your booster seat with backrest is equipped with a spacer (SPS) to distance the backrest from the collision area in the
event of a side impact.
This spacer must be placed on the side of the car door. The spacer is stored in the backrest wing window (12).
To fit it, remove it from its storage position (12) and insert it into the triangle (11) on the side (Fig. J1). It is only
•
necessary to place the SPS on the door side. (Fig. J2).
BACKREST SIDE WIDTH ADJUSTMENT
For a height above 135cm, the iWinner is equipped with side wings that can be adjusted in width for the comfort of
the child.
Pull out the knob on the side panel (9) and turn it to adjust the width of the side wings (Fig. K1).
In some cars, when opening the side wings, they may be in a position that interferes with some parts
WARNING:
of the vehicle and therefore, only in these positions, there could not be fully compatible.
MAINTENANCE
Do not expose the upholstery to sunlight for long periods.
Clean the plastic parts with soap and warm water and then dry all the parts thoroughly.
The upholstery can be removed for washing.
20
