Fasten the car belt buckle and guide the belt through the lap belt guides (4) (Fig. F4).
•
HEADREST HEIGHT ADJUSTMENT
The height of the headrest is adjusted by means of a pneumatic piston. To release it, press the push button on the back
of the headrest (2), the headrest will raise automatically. To lower it, push the headrest downwards while pressing the
button (Fig. G1).
Fit the child in the booster seat, the shoulder belt of your car should be inserted through the belt guide in the side of
•
the headrest (3). (Fig. G2)
Adjust the height of the headrest by pressing the button (2). The belt should be slightly above the child's shoulder (Fig. G3).
•
INSTALLING THE CHILD IN THE SEAT
Fit the child in the booster, the shoulder belt of your car should be inserted through the belt guide in the side of the
•
headrest (3). (Fig. H1)
Pull the belt over the child, fasten the buckle and guide the belts through both lap guides (4). (Fig. H2)
•
When removing the child from the booster it is not necessary to remove the belt from the shoulder belt guide (3), it will
be easier to buckle the child when using the booster again.
When the booster seat is not occupied, it must be fastened with the vehicle seat belt, in the event of
WARNING:
sudden braking or an accident it could be ejected and cause injury to people in the car.
To remove the booster seat:
Release the ISOFIX anchorages by pressing the buttons (6).
•
Remove the booster seat. Slide the ISOFIX anchorages (5) back into the base for storage.
•
EN
19
