Scheppach BMS200-88 Originalbetriebsanleitung Seite 31

Danger from noise
Hearing damage
Prolonged unprotected work with the device may
cause hearing damage.
– Always wear hearing protection as a matter of principle.
Behaviour in an emergency
In the event of an accident, initiate the necessary first
aid measures and seek medical assistance as quickly
as possible.
The product has been built according to state-of-the-
art and the recognised technical safety rules. However,
individual residual risks can arise during operation.
• Furthermore, despite all precautions having been met,
some non-obvious residual risks may still remain.
• Residual risks can be minimised if the "Safety In-
structions" and the "Intended Use" together with the
operating manual as a whole are observed.
• Keep your hands away from the working area when
the product is in operation.
7. Technical data
Dimensions L x W x H
Mower unit for cutter
bar mower width
Number of blades
Cutting speed
Cut height
Speed
Wheel diameter
Handlebar height
Weight
Drive
Type of motor
Displacement
Idle speed
Maximum speed
Engine starter
Power
Fuel
organic ethanol content of 5%
Fuel tank capacity
Required engine oil
1265 x 920 x 1300 mm
880 mm
18 pcs.
800 m/s
30 - 60 mm
2.52 km/h
320 mm
830 / 970 / 1100 mm
55 kg
1-cylinder.
4-stroke OHV engine
196 cm³
1800 - 2200 rpm
3300 rpm
Cable pull
4.2 kW
Unleaded petrol from octane
rating 90 and maximum
SAE 10W-30 / SAE 10W-40
www.scheppach.com
CO output
2
Engine oil tank capacity
Subject to technical changes!
Noise and vibration
m Warning: Noise can have serious effects on your
health. If the machine noise exceeds 85 dB, please
wear suitable hearing protection.
Information on noise level per ISO 11094:1991; EN
ISO 3744
Noise data
Sound power level L
Sound pressure level L
Uncertainty K
wa/pA
m WARNING!
In case of extended working periods, the operat-
ing personnel may suffer circulatory disturbances
in their hands (vibration white finger) due to vibra-
tions. Raynaud's syndrome is a vascular disease
that causes the small blood vessels on the fingers
and toes to cramp in spasms. The affected areas
are no longer supplied with sufficient blood and
therefore appear extremely pale. The frequent use
of vibrating products can cause nerve damage in
people whose circulation is impaired (e.g. smokers,
diabetics). If you notice unusual adverse effects,
stop working immediately and seek medical advice.
Vibration parameters
Vibration value per EN 12733:2018
Vibration a
h
Uncertainty K
h
8. Unpacking
• Open the packaging and carefully remove the product.
• Remove the packaging material, as well as the pack-
aging and transport safety devices (if present).
• Check whether the scope of delivery is complete.
• Check the product and accessory parts for transport
damage. In the event of complaints the carrier must
be informed immediately. Later claims will not be
recognised.
1 l
• If possible, keep the packaging until the expiry of the
warranty period.
744 g/kWh
WA
pA
13.647 m/s²
0.6 l
101.6 dB
65.21 dB
2.01 dB
1.5 m/s²
GB | 31
