˜ Residual risks
Even if you are operating this product
in accordance with all the safety
requirements, potential risks of injury and
damage remain. The following dangers
can arise in connection with the structure
and design of this product:
Injuries caused by moving parts or hot
surfaces
Ear damage if working without ear
protection
Damage to your health caused by
swinging your hands and arms when
operating the product for longer
periods of time or if the unit is not held
or maintained properly
NOTE
This product produces an
u
electromagnetic eld during
operation This eld may under
some circumstances interfere with
active or passive medical implants!
To reduce the risk of serious or fatal
injury, we recommend persons with
medical implants to consult their
doctor and the medical implant
manufacturer before operating this
product!
˜
˜ Unpacking the product
1. Take the product out of the packaging
and remove all packaging materials
and plastic wrappings.
2. Check to make sure that all listed parts
are included see "Scope of delivery" .
3. Check whether the product and all
parts are in good condition, if any
damage or defect is detected, do
not use the product, but follow the
procedure described in chapter
"Warranty".
˜ Accessories
WARNING!
m
Do not use accessories not
u
recommended by
may result in electric shock or re.
To operate this product safely and
correctly, the following accessories, i.e.
tools and accessory tools, are necessary:
Insertion tool for
o
holder :
1 ] [
Bit holder and screw bit
–
Socket adapter and socket
–
Suitable personal protective equipment
o
Accessories and accessory tools are
available through your authorised dealer.
When buying always consider the
technical requirements of this product (see
"Technical data" . If you are not certain
ask a uali ed specialist and get advice
from your trusted dealer.
˜ Preparation
WARNING! Risk of injury due to
m
i i
Only insert the battery pack
u
the product is fully prepared for use.
˜ Attaching/removing an
insertion tool
NOTE
The directional information in this
u
section should be interpreted as
meaning that the user is positioned
behind the product.
Attaching an insertion tool
Fig. D
1. Unlocking the tool holder
locking sleeve
2 ] [
. This
.35 mm tool
‑
once
7 ] [
: Slide the
1 ] [
backwards.
GB/IE 37
