Slide the lid (13) on to the grass catcher and secure it in place using five ST6.3×7.9
bolts and rubber washers ø 6.4/14-1.2.
3.6.3g
Attach the face plate (14) to the frame of the grass catcher using two M12×16 bolts.
3.6.3h
Attach two couplers (12) to the lateral sides of the grass catcher. For this purpose,
use four ø10.5×10 pins and ø2.5×38 cotter pins. Insert the pins into the holes from
the external side of the grass catcher, insert the cotter pins from the inner side of the
3.6.3i
grass catcher.
Finally reattach the flexiglass cover (4), slide out the service rod (3) and put it back
into the holder on the lateral side of the frame.
Start up the machine and using the UP-DOWN switch lower the grass catcher to the
3.6.3j
bottom end position. Turn off the machine.
Using the supplied nuts and bolts, screw the ballast and the clutch covers to the left
and right side of the machine's frame at the front underneath the bumper bar. This
completes the assembly of the grass catcher.
3.6.3k
