The user's manual for the operation of the riding mowers is supplemented with and amended by the
High-dump grass catcher in the following chapters as follows:
1.1 | USE
1.1.1 High-dump grass catcher
The High-dump grass catcher with extended dumping distance is designed to be attached to riding
mowers and serves to collect grass clippings and then lift them up to the necessary height to be
dumped out on to a transport vehicle or into a container. The grass catcher is lifted by means of
a hydraulic motor connected to the internal hydraulic system of the mower's gear box. The grass
catcher is dumped out by an electric linear actuator. The functions of the grass catcher are controlled
using a switch-controlled electronic system.
1.2 | MAIN PARTS OF THE RIDING MOWER
1.2.1 Main parts of the high-dump grass catcher
(1) Frame
(2) Chute scraper
If needed, use it to clean the ejection chute
(3) Service rod
(4) Plexiglass cover
(5) Grass catcher carrier
(6) Full grass catcher sensor
(7) Grass catcher control elements
(8) Grass catcher bracket
1.2.1
(9) Grass catcher presence sensor
(10) Linear motor
(11) Grass catcher
(12) Couplers
(13) Lid
(14) Grass catcher face plate
1.3 | LABELS ON THE MOWER
LABELS ON THE HIGH-DUMP GRASS CATCHER
It is permitted to use
Danger the lifting mechanism
up to an incline of 4°
In order to leave
the grass catcher in
The maximum the raised position,
load for the lifting it is necessary to
mechanism is 60 kg. mechanically secure
the grass catcher
against it falling
19
Reversing with
a raised grass
catcher is only
permitted at a low
speed
