3.0 Specification
Maximum flow rate
Maximum cooling capacity
Max suction lift
Max discharge height
Maximum horizontal run
Electrical rating
Energy consumption idle
Alarm relay rating
Temperature protection
Protection class
Ingress protection
Operating temperature
Water temperature
Storage temperature range
Sound
Discharge tube (not incl.)
Overall dimensions
Pump body
Sensor reservoir
Net weight
Pump body
Sensor reservoir
Colour
Conformity
Instruction Manual
22 l / h (6 GPH)
18.5 kW (63'000 BTU/h)
2 m (6.6 ft)
15 m (50 ft)
75 m (250 ft) at 0 m head and
0 m suction
100-240 VAC, 50-60 Hz, 6 W
0.6 W
Zero volt, normally closed (NC),
failsafe, 5 A 250 VAC, 5 A 30
VDC
Software–controlled sensor
II
Fully potted IP44
Cable connector IP44
3 °C – 40 °C (37 °F – 104 °F)
3 °C – 40 °C (37 °F – 104 °F)
-20 °C – 70 °C (-4 °F – 158 °F)
<20 dB(A) at 1 m (3 ft) distance
¼" or 6 mm
30 × 26 × 122 mm (1.2 × 1.0 × 5.0")
38 × 26 × 54 mm (1.5 × 1.0 × 1.7")
130 g (4.6 oz)
80g (2.8 oz)
Black (RAL 9001)
CE, Motor-Operated Water
Pumps UL 778 and Liquid
Pumps CSA C22.2 #108 and UL
2043
Enclosure type 2
