Release button (battery pack)
11 ] [
LED work light
[ 12 ]
Speed level display
13 ] [
button (speed level)
14 ] [
On/off switch
[ 15 ]
(Fig. B)
Charger *
[ 16 ]
(Fig. C)
Storage case
17 ] [
(Fig. D)
Bit holder *
[ 18 ]
Socket adapter *
[ 19 ]
* Not included in delivery.
˜ Functional description
The product features a ¼" (6.35 mm)
o
hexagon tool holder
rotate clockwise and counter-
clockwise .
The rotary impact function converts
o
the force of the motor into uniform
rotary impacts .
The striking mechanism switches on
o
when tightening and loosening screws
and nuts .
Read the section "Operation" to learn
o
more about each operating element's
function .
˜ Technical data
20V Cordless
impact wrench
Rated voltage U:
Weight (with
battery pack):
No-load rotation
speed n :
0
- Level 1:
- Level 2:
- Level 3:
- Level 4:
which can
[ 1 ]
PDSSAP 20‑Li D3
20 V
approx. 1.7 kg
0–1,900 min
−1
0–2,400 min
−1
0–3,050 min
−1
0–3,600 min
−1
Impact rate:
- Level 1:
- Level 2:
- Level 3:
- Level 4:
Torque:
- Level 1:
- Level 2:
- Level 3:
- Level 4:
Max . screw/nut
size:
Tool holder:
PARKSIDE
Performance
Smart battery
Frequency band:
Transmitted power: ≤ 20 dBm
Recommended ambient temperature
Max . temperature
(total):
While charging:
During operation:
During storage:
Noise emission value
The measured values have been
determined in accordance with EN 62841.
The A-rated noise level of the product is
typically as follows:
Sound pressure level L
Uncertainty K :
pA
Sound power level L
Uncertainty K :
WA
0–1,200 min
−1
0–2,400 min
−1
0–3,800 min
−1
0–4,300 min
−1
120 N m
150 N m
190 N m
226 N m
M16
¼" (6.35 mm)
hexagon drive
Smart PAPS 204
A1/Smart PAPS
208 A1
2,400–2,483.5 MHz
+50 °C
+4 °C to +40 °C
+4 °C to +50 °C
0 °C to +45 °C
: 71 .3 dB
pA
3 .0 dB
: 79 .3 dB
WA
3 .0 dB
