Classic schema :
Schema example + reduced power :
Example of a loop connection :
I. When one end of the fence is
connected to terminal 3 of the unit,
the LED B allows to monitor the
proper functioning of this fence.
Wire connected to
"FULL OUTPUT TERMINAL"
Wire connected to
"REDUCED OUTPUT
"REDUCED POWER" :
Allows for example to make pens for animals in a state of temporary
weakness (after calving, ... etc.) or susceptible animals while maintaining other
enclosures at maximum power.
Insulator
B
3
3
Insulator
II. In this configuration :
- if the green LED (B) lights, the loop is correct (a circuit is achieved)
- If the green indicator (B) is not lit, the wire is cut.
In this case the two segments of the connexion the outward pulses remain
electrified. But that of the return to the energiser remains at a reduced
power.

ALL DEVICES
Insulator
 CLOVERT S60
 CLOVERT S60 D
Insulator
TERMINAL"

CLOVERT S60

CLOVERT S60 D
Fence wire connected to the
"HIGH OUTPUT POWER"
the terminal "REDUCED OUTPUT"
— 9 - § EN —
Insulator
and then looped to
Insulator
Insulator
Insulator
