RT-155H/HB/E
FOR A COMPLETE
DESCRIPTION
OF THE OPERATION
OF THIS UNIT,
PLEASE
REFER TO THE OPERATION
MANUAL.
SPECIFICATIONS
0.27% (DIN 45 511)
Frequency response:
Normal tape;
40 — 12,000 Hz (DIN 45 511)
50 — 11,000 Hz +3 dB
MAXELL
UDXLII tape;
40 — 13,000 Hz (DIN 45 511)
50 — 12,000 Hz +3 dB
TDK Metal tape;
40 — 15,000 Hz (DIN 45 511)
|
50 — 13,000 Hz +3 dB
NAMES
OF PARTS
Power Switch
Cassette Compartment
Digital tape Counter
Tape Counter Reset Button
Power Indicator
Sharpscan Peak Level Display Meter
Stop/Eject Button
Record Button
Play Button
10 Rewind Button
11
Fast-Forward Button
15 Tape Selector Switches
16 Record Level Controls
17 Headphones Jack
18 Line Output Socket
19 Line Input Socket
20 Input Selector Switch
21
Din Record/Playback (Input/Output) Socket
22 AC Voltage Selector (RT-155H/HB Only)
23 AC Power Supply Cord
OANDOFPWHNH
—
Figure 2-2
