Final tasks
4
1 2
1 2
2
2
2
2
1
3
4
4
IMPORTANT! Do not lay the cable in
front of the fan!
Lay the cable above the fan and secure
with the cable tie.
Fix the cable in place using 3 cable
12
1 2
ties
Trim cable ties
13
Insert cover
1
Fit the cover using 6 TX25 screws
2
2
Tightening torque = 3 Nm
2
Insert the side panel
3
Secure the side panel using 3 TX25
4
screws
Tightening torque = 3 Nm
Screw on the T connector at the
5
rear
Affix the 1-4 bar sticker
6
Connect the cooling unit to the
7
6
power source
13
