Installing the
The installation of the OPT/CU Torch Deflate is described with reference to a CU
OPT/i CU Torch
1400i Pro/MC cooling unit.
Deflate
The installation in a CU 1100i cooling unit is carried out in the same way.
1
2
100 mm
80 mm
Insert the solenoid valve with ser-
1
rated washer into the opening from
the inside to the outside as shown
Screw on the 17 mm hexagonal nut
2
Tightening torque = 5 Nm
Cut 2 sections of white hose to
3
length:
1 x 80 mm
1 x 100 mm
Connect the hose sections, shuttle
4
valve, and non-return valve toge-
ther as shown
Connect hose sections and con-
5
nectors to the solenoid valve as
shown
Cut the hose from the pump to the
6
height of the Y-connector
