1
2
NOTE! The following step only applies to US power sources:
3
The tension relief (7) is subsequently required for the mounting of the Uni Box as
described below.
Open up Uni Box
case
Opening up of Uni Box case
Mount Uni Box to
power source
Mounting Uni Box to power source
NOTE! The following step only applies to US power sources:
1
2
Close power
IMPORTANT! Before mounting the side panel, make sure that the cables are not
source
clamped, buckled nor tensioned.
12
Loosen four screws (6) at the rear side panel of the power source
Tilt rear side panel of the power source forward and remove by lifting
Remove the tension relief (7)
(8)
(9)
(11)
(11)
(12)
Insert the tension relief dismantled before (7) - see Fig.6 - at the bottom pa-
nel of the Uni Box (pos. 12)
Fix tension relief
•
at the 2 outer drillholes at the side with the 4 drillholes
•
by means of screw and shim at the opposite side
Loosen two screws (8) at the top
1
(8)
panel of the Uni Box (8) and remo-
ve case cover (9)
Plug the LocalNet connecting so-
1
cket of the power source in the Lo-
(11)
calNet connection (10) of the Uni
Box
Fix LocalNet connecting socket by
2
means of cap nut
Insert Uni Box at rear side panel of
3
power source and tighten by me-
ans of 3 screws at the respecitve
positions (11)
(10)
