Mounting of conversion set
Safety
Danger from incorrect operation and work that is not carried out properly.
This can result in serious personal injury and damage to property.
▶
▶
▶
Danger from electric current.
This can result in serious personal injury and damage to property.
▶
▶
Dismantle Local-
Net connecting
socket
Dismantle rear
side panel of
power source
WARNING!
All the work and functions described in this document must only be carried
out by technically trained and qualified personnel.
Read and understand this document in full.
Read and understand all safety rules and user documentation for this device
and all system components.
WARNING!
Before starting work, switch off all the devices and components involved and
disconnect them from the grid.
Secure all the devices and components involved to prevent unintentional re-
starting.
(6) (6)
Dismantle the left side panel on
1
the power source seen from the
front
Dismantle the LocalNet connecting
2
socket by loosening both screws
(5)
Loosen the four screws at the rear
(5)
3
panel of the power source
(6)
(6)
(6)
(6)
(7)
