EN
24
INSTALLATION
If you have an outlet to the outside, your cooker
hood can be connected as below picture by means
of an extraction duct (enamel, aluminum, flexible
pipe or non-flammable material with an interior
diameter of 120 mm)
1.
Before installation, turn the unit off and unplug
it from the outlet.
2.
The cooker hood should be placed at a height
of 65-75cm above the cooking surface for best
efficiency.
3.
Install the cooker hood between two
cupboards. Drill and screw on the side
boards of the cupboards (the holes ≤ 2mm).
The distance between the head of the screw
and the side board should be 5mm, and the
distance between the screw and the cooking
surface should no less than 1040mm. If there
is not room enough, you can place it higher or
lower.
4.
Hang the cooker hood on the screws between
the two cupboards.
