4.4.5
Kommando-Objekte
Index 60n0 HART Command 3 (für n=8: Kanal 1)
Index (hex) Name
60n0:0
HART Cmd3
60n0:01
Field Device
Status
60n0:02
Cyclic Frame Cnt
60n0:05
Primary Variable
Units Code
60n0:06
Secondary
Variable Units
Code
60n0:07
Tertiary Variable
Units Code
60n0:08
Quaternary
Variable Units
Code
60n0:09
Primary Variable
Loop Current
60n0:0A
Primary Variable
60n0:0B
Secondary
Variable
60n0:0C
Tertiary Variable
60n0:0D
Quaternary
Variable
ELX4181
Bedeutung
Maximaler Subindex
Represent the current state of the slave
Cyclic Frame Counter
Primary Variable Units Code (refer to HART 'Common Table
Specification')
Secondary Variable Units Code (refer to HART 'Common Table
Specification')
Tertiary Variable Units Code (refer to HART 'Common Table
Specification')
Quaternary Variable Units Code (refer to HART 'Common Table
Specification')
Primary Variable Loop Current (units of milli-amperes)
Primary Variable (Herstellerspezifisch)
Secondary Variable (Herstellerspezifisch)
Tertiary Variable (Herstellerspezifisch)
Quaternary Variable (Herstellerspezifisch)
Version: 2.1.0
Parametrierung und Programmierung
Daten typ
Flags
UINT8
RO
UINT8
RO
UINT8
RO
UINT8
RO
UINT8
RO
UINT8
RO
UINT8
RO
REAL32
RO
REAL32
RO
REAL32
RO
REAL32
RO
REAL32
RO
Default
0x0D (13
)
dez
0x00 (0
)
dez
0x00 (0
)
dez
0x00 (0
)
dez
0x00 (0
)
dez
0x00 (0
)
dez
0x00 (0
)
dez
0x00000000
(0
)
dez
0x00000000
(0
)
dez
0x00000000
(0
)
dez
0x00000000
(0
)
dez
0x00000000
(0
)
dez
