4. Repeat step 3 until you have formed a complete circle.
Note
The ends of the frame poles (1) must be completely inside the connectors (9).
5. Insert one screw (14) with a washer (13) into the drill hole of each connector (9) and tighten the screw with the
hex key (15).
6. Repeat step 5 until all frame poles (1) are screwed with the connectors (9).
7. Place a foot (7) on the bottom openings of the connectors (9) and fasten each with a washer (13), a spring ring
(12) and a screw (14).
Note
The feet (7) must be pointing outwards.
8. Repeat step 7 until a foot (7) has been fastened under each connector (9).
7.2 Installing the jump mat
The jump mat (5) is tightened with 30 rubber straps (6). The order of insertion is important for ensuring even distribu-
tion of forces. Following the proper order makes assembly easier and safer. Proceed as follows:
1. Spread out the jump mat (5) with safety net (5a) within the base frame. Make sure that the safety net (5a) is on
top of the jump mat.
WARNING!
Be careful when inserting the rubber straps (6)! The rubber straps (6) are under tension during insertion! There is a
risk of injury!
WARNING!
Be careful when inserting the rubber straps (6) and follow the instructions below precisely so that the jump mat (5) is
set up properly. Otherwise there is a risk of injury!
Note
The jump mat (5) is equipped with 30 eyelets (5b). Place the jump mat (5) in the middle of the base frame such that
the opening of the safety net (5a) is between two feet (7).
2. Take the eyelet (5b) (point 0) directly below the entrance to the safety net (5a) and pull the rubber strap (6) with
the end of the strap (6a) through it until the ball (6b) of the rubber strap (6) is on the side of the eyelet (5b).
3. Place the end (6a) of the rubber strap (6) onto the frame between two feet (7).
4. Pass the strap tensioner (10) through the end of the strap (6a) below the frame.
5. Grab the ball (6b) of the rubber strap (6) with the hook of the strap tensioner (10) and press the strap tensioner
(10) vertically downwards. The rubber strap (6) is tightened towards the jump mat (5) with the strap tensioner
(10).
6. Lever the strap tensioner (10) all the way back and pull the ball (6b) below the rubber strap (6a) back.
7. The end of the strap (6a) contains the ball (6b) of the rubber strap (6), and you can remove the hook of the
strap tensioner (10) from the ball (6b) of the rubber strap (6).
