6. Selecting a location
• The trampoline is suitable for indoor and outdoor use.
• Carefully select the location of the trampoline. The trampoline must not be set up over a hard surface.
• The trampoline must not be set up on a smooth (e.g. tiled) surface. It could slip!
• Set up the trampoline on a level surface at least 2m away from other structures and obstacles such as stairs,
fences, garages, houses, protruding branches, washing lines or electrical lines. Make sure that there is sufficient
room above the trampoline. Do not set it up near windows, walls, trees, etc. There should be a clear space of at
least 7.5m above the trampoline.
• The trampoline must not be set up on concrete, asphalt or similarly hard surfaces, nor near colliding structures
such as paddling pools, swing sets, slides, jungle gyms, furniture etc.
• The trampoline must not be embedded in the ground.
• Set up the trampoline in a safe location so that it cannot blow away or tip over!
• Locate the trampoline so that others cannot use it unsupervised, and secure it against unauthorised use!
7. Assembly
Remove all parts from the packaging and check whether all parts are fully present. If there are any parts missing,
please contact our customer service.
WARNING!
Due to its size, the trampoline must be assembled and installed by at least two adults.
WARNING!
Wear protective gloves when assembling the trampoline and make sure that you are working deliberately and
carefully. Make sure that you do not get caught in any parts! There is a risk of injury!
Note
Use the separate assembly instructions for assembly. The necessary information on the individual steps is presented
visually.
7.1 Assembling the base frame
The base frame must be made up of multiple frame poles (1). Proceed as follows:
1. Find a suitable location for the trampoline. You can find more information in section '6 Selecting a location'.
2. Lay one frame pole (1) and one connector (9) in alternating fashion to form a circle.
Note
The frame poles (1) are narrower at one end than at the other. Lay the frame poles (1) and connectors (9) in a circle
so that each narrow and broad end of a frame pole (1a/1b) is next to a connector (9). The drill holes of the con-
nectors (9) are facing outwards.
3. Insert the broad end of a frame pole (1a) into a connector (9) and, on the other side, the narrow end of another
frame pole (1b).
Note
Always insert the broad end of a frame pole (1a) into a connector (9) before inserting the narrow end (1b) on the
other side.
