WARNING!
Always use the strap tensioner (10) to secure the rubber straps (6). Make sure that the rubber strap (6) is completely
pulled around the ball (6b). Otherwise there is a risk of injury!
8. Count another 10 eyelets (5b) down and secure the 11th eyelet (5b) to the frame with a rubber strap (6).
9. Count another 10 eyelets (5b) down and secure the 21st eyelet (5b) to the frame with another rubber strap (6).
10. Starting at point 0, count 5 eyelets (5b) down and secure it to the frame with a rubber strap (6). Then count an-
other 10 eyelets (5b) down and secure the 15th down and secure it to the frame with a rubber strap (6). Repeat
this until you have returned to point 0.
11. Fasten the rest of the eyelets (5b) to the frame with the rubber straps (6) in any order.
7.3 Securing the frame padding
The frame padding (11) protects against making contact with the rubber straps (6). The additional crawling and
stumble guard (11a/11b) ensures extra safety outside of the trampoline. It must be carefully installed so that no inju-
ries can occur while jumping and/or falling. Proceed as follows:
1. Place the frame padding (11) on the frame poles (1) so that you can place each opening of the frame padding
(11) over an opening of the connector (9a).
2. Pull the crawling guard (11a) downward around the trampoline.
Note
There is a stumble guard (11b) over each foot.
3. Tie the ends of the crawling guard bands (11c) together and pull them over the end of the foot (7).
4. Pull the rubber straps (11d) of the stumble guard (11b) over the end of the foot (7).
5. Repeat steps 3 and 4 until the crawling guard bands (11c) and rubber straps (11d) of the stumble guard (11b)
are fastened to each foot (7).
Note
The stumble guard (11b) must be positioned over the foot (7).
7.4 Installing the safety net
The safety net (5a) is fastened onto the pole caps (8) with safety net straps (5c). The pole caps (8) are placed on
the net poles (2) that are fastened onto the connector (9) with the net poles (3). Proceed as follows:
1. Connect the net poles (2) and (3) to each other.
2. Place the end of the net pole (3) on the opening (9a) of the connector (9).
3. Repeat steps 1 and 2 five times.
Note
The net poles (2) and (3) must arch outwards.
4. Pull a pole sleeve (4) over the net poles (2) and (3).
5. Repeat this step five times.
6. Place a pole cap (8) on the end of the net pole (2).
7. Repeat this step five times.
