STEP 4
1. Spread out the jump mat (5) with safety net (5a) within the base frame. Make sure that the safety net (5a) is on
top of the jump mat.
WARNING!
Be careful when inserting the rubber straps (6)! The rubber straps (6) are under tension during insertion! There is a
risk of injury!
WARNING!
Be careful when inserting the rubber straps (6) and follow the instructions below precisely so that the jump mat (5) is
set up properly. Otherwise there is a risk of injury!
Note
The jump mat (5) is equipped with 30 eyelets (5b). Place the jump mat (5) in the middle of the base frame such that
the opening of the safety net (5a) is between two feet (7).
2. Take the eyelet (5b) (point 0) directly below the entrance to the safety net (5a) and pull the rubber strap (6) with
the end of the strap (6a) through it until the ball (6b) of the rubber strap (6) is on the side of the eyelet (5b).
3. Place the end (6a) of the rubber strap (6) onto the frame between two feet (7).
4. Pass the strap tensioner (10) through the end of the strap (6a) below the frame.
5. Grab the ball (6b) of the rubber strap (6) with the hook of the strap tensioner (10) and press the strap tensioner
(10) vertically downwards. The rubber strap (6) is tightened towards the jump mat (5) with the strap tensioner
(10).
6. Lever the strap tensioner (10) all the way back and pull the ball (6b) below the rubber strap (6a) back.
7. The end of the strap (6a) contains the ball (6b) of the rubber strap (6), and you can remove the hook of the
strap tensioner (10) from the ball (6b) of the rubber strap (6).
WARNING!
Always use the strap tensioner (10) to secure the rubber straps (6).
Make sure that the rubber strap (6) is completely pulled around the ball (6b). Otherwise there is a risk of injury!
8. Count another 10 eyelets (5b) down and secure the 11th eyelet (5b) to the frame with a rubber strap (6).
9. Count another 10 eyelets (5b) down and secure the 21st eyelet (5b) to the frame with another rubber strap (6).
10. Starting at point 0, count 5 eyelets (5b) down and secure it to the frame with a rubber strap (6). Then count an-
other 10 eyelets (5b) down and secure the 15th down and secure it to the frame with a rubber strap (6). Repeat
this until you have returned to point 0.
11. Fasten the rest of the eyelets (5b) to the frame with the rubber straps (6) in any order.
4. INSTALLING THE JUMP MAT
