1 probe + reset time
To use this mode, it is necessary to bypass
the high level probe input (11) with ground
(12) and select a reset time between 3 min.
and 99 h.
If the water level drops and the minimum
level probe is discovered, the pump stops.
When the water level touches the probe
again, a time delay starts for the well to
recover. When the timing is over, the pump
starts up again.
●
No probe mode (underload) + reset time
In this type of installation it is essential
to make a CORRECT Imin SETTING
(underload)
In wells and self-priming pumps, it is
possible to work without probes. If the
water level falls below the pump suction,
the current consumed drops and can be
detected.
To use this mode, it is necessary to bridge
the two probe inputs (11 - 12) with earth
(13) and select a reset time between 3 min.
and 99 h. When the equipment detects the
underload, it stops the pump and waits for
the reset time. . At the end of the timing, the
pump starts again.
1 Sondas + Tiempo de rearme
OK
9 10 11 12 13
9 10 11 12 13
ON
OFF
ON
OFF / Imin
23
