DEVICE DESCRIPTION
The MOD-38 vacuum cleaner combines the convenience of a cyclonic and cordless vacuum
cleaner. Cyclone technology allows you to filter dust without using a dust bag by means of
centrifugal force, which means you only need to empty the dust container over the dustbin.
The lithium-ion rechargeable battery with one of the highest ratios of stored energy to its
weight makes the device lightweight and ensures a long operating time after charging. The
vacuum cleaner is equipped with a two-stage suction power adjustment.
1. Vacuum cleaner switch on the handle
2. Main handle assembly.
3. Main handle folding button
4. Button for releasing the vacuum
cleaner from the main handle
5. Vacuum cleaner
6. Vacuum cleaner switch
7. Status lamp
8. Dust container release button
9. Hook with connection
10. HEPA filter
11. Filter body
12. Dust container
BEFORE FIRST USE
1. Remove the vacuum from the box; remove all stickers, transport protectors, bags and fillers.
2. Check the vacuum for any damages that might have occurred during transport. If you have any
doubts, contact the seller.
3. Assemble the docking station (stand) correctly – attach the
body (19) to the docking station base (18) as shown (fig.1). The
docking station can be removed by releasing the locking mecha-
nism underneath the base (18). Install holders (22) in the guides
(21) where you can park additional vacuum cleaner accessories.
4. Unfold the handle assembly (2) and lock in the extended po-
sition (fig.2). Folding of the handle is possible by pressing the
button (3).
5. Mount the vacuum cleaner (5) in the handle assembly (2) as
shown in the picture (fig.3).
13. Electric brush release button
14. Electric brush
15. Electric brush roll release button
16. Backlight diodes (LED)
17. Charger
18. Docking station (stand) base
19. Docking station (stand) base
20. Charger socket
21. Guide rails for accessory holders
22. Accessory holders
23. Small brush
24. Crevice brush
19
18
fig. 1
