User's Manual
KAYAK
• A recreational vessel designed for use on internal waterways with an expected wind strength reaching Grade
4 on the Beaufort Scale inclusive and a determining wave height of up to 0.3 metres/12 inches inclusive, with
occasional waves up to 0.5 metres/20 inches of height caused e.g. by vessels passing by.
• The boat has been manufactured in compliance with the EN ISO 6185-1 Standard, Category IIIB.
• Related standards: EN ISO 10087, EN ISO 10240, EN ISO 14945.
Dear Customer,
This manual will help you to easily and safely master your vessel.
It contains a detailed description of the vessel, the supplied or built-in
equipment, its sets as well as information about its control and mainte-
nance. Please read it carefully, thereby getting to know the boat before
actually using it.
If this is your fi rst vessel or you have changed the type of vessel and
do not know this type well, please get acquainted with its maintenan-
ce and control prior to your fi rst individual use of the vessel so that it
is safe and comfortable. Your dealer or the National Yacht Federation
or club will recommend you appropriate training courses or qualifi ed
instructors.
Do not pull o until the expected sailing conditions (wind strength and
wave height) are appropriate for the construction category of your ve-
ssel and you and your crew are able to control it in these conditions.
Please store this manual in a safe place and hand it over to the new
owner should you sell the vessel.
1. Table of specifi cations
(Indicative values)
Length (cm) [ft.-in.]
Width (cm) [ft.-in.]
Diameter of sidewall cylinders (cm) [in.]
Number of air chambers
Dimensions of the folded product (cm) [in.]
Dimensions – packed in cardboard (cm) [in.]
Maximum operational pressure
Weight (kg) [lbs.]
Maximum load (kg) [lbs.]
Maximum number of kayakers
Draught (cm) [in.]
Highest anchor above surface (cm) [in.]
2. Technical description – see Fig. 1
1 side tube
2 bottom
3 PUSH/PUSH valve - it allows infl ating/defl ating, re-
gulation and measurement of pressure with a pressure
gauge
4 pressure-relief valve (placed below the top part of the
boat)
5 front seat with a back-rest
6 rear seat with a back-rest
7 foot-rest (placed below the top of the boat)
8 plastic handle
9 manufacturer's label (on the tube)
10 yellow „WARNING" label (sewn into the edge of the kayak)
11 bungee netting
12 black zip with slider
13 footrest strap attachment
14 backrest and footrest attachment
8
SWING 1/024, SWING 2/024
TABLE OF CONTENTS:
1. Table of Specifi cations
2. Technical Description
3. Infl ation Instructions
4. Riding the boat
5. Folding of the boat
6. Treatment and Storage
7. Guarantee Conditions
8. Boat Repairing
9. Product Disposal Method
10. Packaging Disposal Method
11. Type Parameters Tag
12. Safety Caution
SWING 1/024
316 [10-4]
87 [2-10]
20.3 [8]
3
64 × 42 × 24 [25 × 17 × 9]
67 × 44.5 × 26 [26 × 18 × 10]
0.02 MPa [0.2 Bar / 3 PSI]
11.3 [25]
120 [265]
1
15 [6]
40 [16]
15 attachment of the rest to the kayak reinforcement
16 seat attachment (on the bottom)
17 reinforcement attachment (placed below the top part of
the boat - Fig. 2)
18 metal kayak reinforcement
19 tracking fi n attachment
20 safety rope attachment
21 safety rope
22 drain hole
23 collar tunnel
24 plastic reinfocement
25 reinforcement coupling
ACCESSORY SUPPLIED WITH THE KAYAK:
Single-seat version - reinforcements Nos. 1 and 2. Two-seat
version - reinforcements Nos. 3, 4, 5. Transport bag, plastic re-
inforcement of the collar, tracking fi n with user manual, belt for
strapping the folded kayak, user's manual, sponge in a netting
bag, repair kit containing glue, patches and valve adaptors,
metal key for valves.
VERSION 8/2024
EN
page 8
