Specifications
Battery
Type: Lithium-Ion
Designation: AP
The machine may be operated only with
original STIHL AP rechargeable
batteries.
Running time is dependent on the
energy content of the battery.
Abrasive wheels
The quoted maximum permissible
operating speed of the abrasive wheel
must be greater than or equal to the
maximum spindle speed of the cut-off
machine used.
Max. spindle speed: 6650 rpm
Outside diameter: 230 mm
(9 ")
Max. thickness 3 mm
Bore diameter/spindle 22.23 mm
diameter: (7/8 ")
Tightening torque: 20 Nm
(177 lbf. in.)
Composite resin abrasive wheels
Minimum outside diameter 80 mm
of thrust washers: (3.150 in.)
Max. depth of cut: 70 mm
(2.756 in.)
TSA 230
All manuals and user guides at all-guides.com
Diamond abrasive wheels
Minimum outside diameter
of thrust washers:
Max. depth of cut:
Weight
without battery, without
abrasive wheel, with water
connection
Water supply
Max. pressure of water
supply:
Sound and vibration levels
For further details concerning
compliance with the Physical Agents
Directive Vibration 2002/44/EEC, see
www.stihl.com/vib/
Values when cutting concrete under
pressure with diamond abrasive wheel
Sound pressure level
L to EN 60745-2-22: 103 dB(A)
peq
Sound power level L to
w
EN 60745-2-22:
Vibration level a to
hv,eq
EN 60745-2-22:
Left handle:
Handle, right
Values when maximum engine speed
without load with diamond abrasive
80 mm
wheel
(3.150 in.)
70 mm
Sound pressure level
(2.756 in.)
L to EN 60745-2-3:
peq
Sound power level L
EN 60745-2-3:
Values when maximum engine speed
without load with composite resin
3.9 kg
abrasive wheel
(8.6 lbs.)
Sound pressure level
L to EN 60745-2-3:
peq
Sound power level L
EN 60745-2-3:
4 bar
The vibration values quoted above have
(58 psi)
been measured according to a
standardized test procedure and may be
used to compare electric power tools.
Depending on the type of usage, the
vibrations that actually occur may differ
from the values quoted.
The vibration values quoted may be
used for an initial assessment of the
user's exposure to vibrations.
The actual exposure to vibrations has to
be evaluated. This process may also
take into account times during which the
electric power tool is switched off and
times during which it is switched on but
114 dB(A)
running without load.
Observe measures to reduce vibration
exposure to protect the user – see
2
3.5 m/s
section on "Vibrations" in chapter on
2
3.5 m/s
"Safety Precautions and Working
Techniques".
The K-factor in accordance with
Directive 2006/42/EC is 2.0 dB(A) for
the sound pressure level and sound
English
93 dB(A)
to
w
104 dB(A)
72 dB(A)
to
w
83 dB(A)
