Materialliste u-turn trinity
descriptiOn in the
paraglider
Line Hook up point Material (Loop
Material)
Speed System Line
Speed system pulley
Speed system hook
Brake loop webbing Material (Loop
Material)
Brake handle
Brake handle - Brake line conection
Brake handle, fix on riser
Brake, main line
Lines
Shackle
Top Material (front / tail)
Bottom Material (front / tail)
Rib, Profil
V-Tape / V-Ribs
H-Stripe / Tension Stripe
Profile nose reinforcement
Riser
Reinforcement on Profile (A,B,C,D)
Sewing yarn canopy
Sewing yarn lines
Manufacturer
descriptiOn
NYLON 10mm HBT WHITE
COUSIN LINE #12999
PL-PULLEY NYLON
Speedsystem-hook
Nylon10mm tape white
Polyester 20mm Tubular Webbing
HEAVY SWIVEL 8mm
Plastic Cover for Magnetic(Cylinder
type)
DSL 300
upper - DC100
middle - PPSL 120 / DSL 70
main - PPSL 160/200
Mylon Rapid
Dokdo 30
Dokdo 20
Dokdo 30 hard finish
Dokdo 30 hard finish
Dokdo 30 Hard Finish
Nylon line AC round
LIROS 12,5mm Keflar webbing / Poly-
ester cover
NCV 024201450X15000(W420)
Pes Scrim Laminated Pes film SR
scrim
SERAFIL 60, FS(150D/3) (WHITE)
M70020 SERAFIL 40, FS1(225D/3)
(WHITE)
B E T R I E B S H A N D B U C H
technical data, diMen-
siOn, Weigt, sOlidness
NYLON 10mm HBT
Dyneema 1.9mm
PL-PULLEY NYLON
25mm Titanal
Nylon 10mm tape
Polyester 20mm
Stainless Steel 8mm
M30110- Magnetic 20mmX3t
2,1mm / 300daN
details see at TRINITY line configura-
tion (rev2)
Braking load 600kg
40 g/m² PA 6.6
36 g/m² PA 6.6
40 g/m², PA 6.6 HT, HF
40 g/m², PA 6.6 HT, HF
40 g/m², PA 6.6 HT, HF
2,0mm
12,5mm
Pes Scrim Laminated Pes film SR
scrim
150D/3"
225D/3"
|
U - T U R N
|
t r i n i t Y
24 | 25
