Mode
Bicycle mode
Motorcycle mode
Car mode
Ball mode
Manual mode
10.3
Setting the pressure (Fig. 1)
ATTENTION! If the measured pressure is higher than the maximum value that is pre-set in the selected more, the light
illuminates red.
The pressure can also be regulated using the "+" (14) and "-" (13) buttons.
The "+" button can be used to increase the pressure.
The "-" button can be used to decrease the pressure.
10.4
Inflating (Fig. 1)
•
Press the On/Off switch on the pump (9) to start the inflation process.
•
The pump stops automatically as soon as the pre-set pressure is reached.
•
It can also be stopped by pressing the On/Off button on the pump (9) again.
•
After inflating, first remove the adapter (19, 20, 21) from the compressed air hose and then pull the compressed air
hose (16) off the device.
10.5
LED work lamp (Fig. 1)
This product is equipped with an LED work lamp to illuminate the immediate work area and improve visibility in poorly lit
environments.
CAUTION! Do not look directly into the LED work lamp or the light source.
1
Press the LED button (12) again for a short time to switch the LED work light on.
2
Pressing again causes the light to flash in SOS mode.
3
Pressing a third time switches the light off again (the LED work light can also be used when the device is switched off).
www.scheppach.com · service@scheppach.com
Yellow light
< 30 psi
< 2 bar
< 2 bar
< 4 psi
Green light
30-50 psi
2-3 bar
2-3 bar
6-16 psi
Light blue light
Continuous
