Bode 100 Quick Start Guide
Characteristic
OUTPUT, CH1, CH2 connector type
USB interface connector
*...specifications are valid after device has warmed up and reached a stable temperature
Bode 100 power requirements
Supply voltage range
Power demand
Connector type
6.3
System requirements
Table 6-3: System requirements
Characteristic
Processor
Memory (RAM)
Graphics resolution
Graphics card
USB interface
Operating System
Bode Analyzer Suite Software
API Software
6.4
Power Adapter requirements
Table 6-4: Wide-range mains power adapter
Characteristic
Line input voltage / frequency / current
Output voltage / current / power
26
Rating
BNC
USB type B socket
+9 VDC to +24 VDC
< 10 W
Coaxial power socket (2.5 mm / 5.5mm)
Inner conductor is positive
Minimum PC Configuration
Intel Core-i Dual-Core (or similar)
2 GB, 4 GB recommended
Super VGA (1024x768)
higher resolution recommended
DirectX 11 with Direct2D support
USB 2.0 or higher
Microsoft Windows 10 / 11
Bode 100 Revision 2 requires Bode Analyzer
Suite 3.00 or newer.
.NET >= 8.07 or COM or SCPI compatible client
COM is not recommended for new
developments. We recommend using
the SCPI interface instead.
Rating
100...240 V / 47...63 Hz / < 0.5 A
18 Vdc / 1 A / 18 W
OMICRON Lab
