Bode 100 Quick Start Guide
6
Technical data
In this section you can find the most important technical data valid for the Bode 100 Revision 2 device.
You can download a detailed technical data sheet for Bode 100 Revision 1 as well as
Bode 100 Revision 2 from the OMICRON Lab website
lab.com
→ Bode 100 → Technical Data.
NOTICE
Risk of permanent damage of the device.
Exceeding the absolute maximum ratings might result in equipment damage.
► Do not exceed the absolute maximum ratings listed below.
6.1
Absolute maximum ratings
Table 6-1: Absolute maximum ratings
Characteristic
dc Power Input
Max. dc supply voltage
Max. dc supply reverse voltage
INPUT CH 1, INPUT CH 2 connectors (1 MΩ input impedance selected)
Maximum dc input signal
Maximum ac input signal
INPUT CH 1, INPUT CH 2 connectors (50 Ω input impedance selected)
Maximum input power
Maximum input voltage
OUTPUT connector
Maximum reverse power
Maximum reverse voltage
24
www.omicron-
Absolute Maximum Rating
+28 V
-28 V
50 V
1 Hz...1 MHz: 50 Vrms
1 MHz...2 MHz: 30 Vrms
2 MHz...5 MHz: 15 Vrms
5 MHz...10 MHz: 10 Vrms
10 MHz ... 50 MHz: 7 Vrms
1 W
7 Vrms
0.5 W
5 Vrms (≤ 3.3 Vdc recommended)
OMICRON Lab
