Bode 100 Quick Start Guide
3.3
Optional accessories
14
B-WIT 100 Wideband Injection Transformer
B-LFT 100 Low-Frequency Injection Transformer
B-WIT 100 and B-LFT 100 are used to inject signals into control
loops. Its main application are the stability analysis of switched
mode power supplies and linear voltage regulators.
B-WIT 100 order number: P0005758
B-LFT 100 order number: P0005773
Passive Probes PML 1110 & PHV 1000-0
PML 111O is a passive 10:1 probe designed for precise low-noise
transfer function measurements.
PHV 1000-O is a passive 100:1 high-voltage probe designed for a
maximum working voltage of 2000 V.
PML 111O order number: B1666600
PHV 1000-O order number: P0008137
B-WIC & B-SMC Impedance test fixtures
B-WIC and B-SMC are designed to extend the impedance
measurement range of Bode 100. They enable you to easily
measure THT or SMD components such as inductors and
capacitors.
B-WIC and B-SMC can be also used in conjunction with the
Bode 500 using N-BNC cables.
The maximum frequency for B-WIC and B-SMC is
50 MHz.
B-WIC order number: P0005760
B-SMC order numer: P0005759
B-TCA Wide Frequency Test Fixture
B-TCA is designed to perform impedance measurements in a wide
frequency range up to 450 MHz using the Bode 500.
B-TCA can be also used in conjunction with the Bode 100 using
two BNC-N cables.
B-TCA order number: P0009653
B-AMP 12 Amplifier
B-AMP 12 boosts the output signal of Bode 100 up to 25 dBm in a
frequency range from dc to 50 MHz.
Order number: P0005772
