Bode 100 Quick Start Guide
Figure 3-2: Bode 100 rear view
NOTICE
Risk of permanent damage of the device.
Exceeding the absolute maximum ratings will result in equipment damage.
► The AC-coupled inputs represent a high impedance for DC signal. Before using passive probes,
check out
4.5 Using external probes & injection transformers
NOTICE
Risk of permanent damage of the device.
Connecting a charged DUT to the Bode 100 can damage the input and output ports.
► Always discharge the DUT (e.g. piezo or capacitor) before connecting it to the Bode 100.
12
on page 20.
OMICRON Lab
