Connecting the product and alignment of the satellite antenna
1 . Remove the protective caps
connector .
[ 2 ]
2 . Connect the output of your LNB with the LNB connector . For this connection purpose,
use the included coaxial cable with F‑plug .
NOTE: If your LNB has more than one output (Example: Quattro LNB), choose
the LNB output to which your satellite receiver is connected . Refer to the instruction
manual the relevant appliance (LNB/satellite antenna/satellite receiver) for selecting
the correct LNB output .
3 . Connect the receiver connector with the antenna input of the satellite receiver .
NOTE: There are 2 wall mounting holes
necessary, make use of those 2 holes to mount the product on a wall . Alternatively,
use the wall holder
4 . Check and verify all the cable connections one more time: Make sure that there
are no loose connections and that connections are correct (Fig . D) . Switch on the
satellite receiver .
5 . The product is now supplied with power via the connected satellite receiver . The
display scale
1 ] [
30 GB/IE
from the LNB connector
10 ] [
to hang the product on a wall .
8 ] [
lights up .
and from the receiver
5 ] [
on the back of the product . If
9 ] [
