Seat Assembly and Removal of MS-3000 PLUS and MS-3000 PLUS MAX
• Seat Assembly:
▪Lift the seat and first insert the slot at the back of the seat into the bracket behind the seat.
▪Pull the bar under the seat and insert the groove at the front of the seat into the bracket in front of
the seat.
▪The position of the small bracket can be adjusted forward and backward to fine-tune the seat posi-
tion.
• Seat Disassembly:
▪Pull the bar under the seat and lift the seat upwards to remove it.
Folding the MS-3000 PLUS and MS-3000 PLUS MAX
• Ensure the scooter is on a flat surface and the seat is removed before folding.
• Pull up the large red ball on the right side to fold the scooter successfully.
• After folding, you can tow the scooter by pulling the directional bar. If you need to transport it in a
car, open the quick release handle on the directional bar and rotate the loose nut to adjust the bar
to its lowest height. (Refer to Section Folding the MS-3000 and MS-3000 MAX for more details.)
Unfolding the MS-3000 PLUS and MS-3000 PLUS MAX
• To unfold, pull the handle of the small red ball located below to release the folding lock.
• Then, pull the scooter back and forth to complete the expansion.
• Refer to the pictures below for assistance.
FOLDING & UNFOLDING
