MS-3000 TECHNICAL SPECS
Parameters
Overall Dimensions (L x W x H)
Folded Dimensions (L x W x H)
Seat Height (from ground)
Backrest Height (from seat)
Max Loading Weight
Max Loading Weight for Child Seat
Net Weight without Battery
Net Weight with Battery
Battery
Battery Charge
Battery Charge Time
Range
Airline Approval
Max Speed - Level I
Max Speed - Level II
Max Speed - Level III
Motor
Climbing Angle Max Degrees
Max Safe Slope
Static Stability
Brake
Turning Radius
Reversing Width
Front Wheel Diameter
Rear Wheel Diameter
Seating Area Width
Cushion Size (width x depth)
Tire pressure (for pneumatic tire)
Optional Parts (Add-ons)
* The actual range of our product can vary due to factors such as weather conditions, load weight, and terrain type. Extreme tem-
peratures, heavy loads, and challenging terrains can all impact battery efficiency and reduce travel distance. While designed for
versatility, users should be mindful of these variables to optimize their range and maintain reliable performance.
* * The widest distance between armrest support bars.
MS-3000 (Standard Range)
40"x21"x35" (1016x534x890 mm)
21.5"x14.5"x29.5"(546x368x750mm) 21.5"x14.5"x29.5"(546x368x750mm)
22" (558mm)
12" (305mm)
265 lbs (120 kg)
66 lbs (30 kg)
60 lbs (27.3 kg)
67 lbs (30.4 kg)
36V 10AH lithium-ion
AC 100-240V, 50Hz,1.5-5A
6 to 8 hours
Up to 16 mile
(25km)*
Not approved
3.7 mph (6 km/h)
7.5 mph (12 km/h)
12 mph (18 km/h)
2 * 250W (Total 500W)
9°
9°
9°
Rear Disc Brake
≤ 59" (1500 mm)
≤ 61" (1550 mm)
10" (254 mm)
8" (200 mm)
10" (254 mm)
**
10" (254 mm) x 9" (228 mm)
30 psi (2 kgf/cm2)
Front & rear basket
41
MS-3000 (Long Range)
40"x21"x35" (1016x534x890 mm)
22" (558mm)
12" (305mm)
265 lbs (120 kg)
66 lbs (30 kg)
60 lbs (27.3 kg)
68 lbs (30.8 kg)
36V 15.6AH lithium-ion
AC 100-240V, 50Hz,1.5-5A
6 to 8 hours
Up to 25 mile
(40km)*
Not approved
3.7 mph (6 km/h)
7.5 mph (12 km/h)
12 mph (18 km/h)
2 * 250W (Total 500W)
9°
9°
9°
Rear Disc Brake
≤ 59" (1500 mm)
≤ 61" (1550 mm)
10" (254 mm)
8" (200 mm)
16" (406 mm)
**
10" (254 mm) x 9" (228 mm)
30 psi (2 kgf/cm2)
Front & rear basket
