erator is responsible for accidents causing
injury to other people or damage to prop-
erty.This­equipment­is­not­suitable­for­com-
mercial­use.­Commercial­use­will­invalidate­
the guarantee.
The­device­is­part­of­the­(Parkside)­
X 20 V TEAM­series­and­can­be­opera-
ted­using­(Parkside)­X 20 V TEAM­series­
batteries.­The­batteries­may­only­be­char-
ged­using­chargers­from­the­(Parkside)­
X 20 V TEAM­series.

General description

The­illustration­of­the­most­im-
portant functional compo-
nents can be found on the
front and the back fold-out pages.

Extent of the delivery

Carefully unpack the appliance and check
that­it­is­complete:
- Cordless circular hand saw
- Parallel guide
-­ Saw­blade­Ø­150­mm­(pre-assembled)
-­ Hex­key­(stowed­in­tool)
- Adapter for external dust extraction
- Case
-­ Instruction­Manual
Battery and charger are not
included.

Overview

1 Switch lock
­ 2­ On/Off­switch
3 Handle
4 Cutting depth scale
5 Hex key
6 Retaining screw
(cutting­depth­scale)
7 Baseplate
8 Auxiliary handle
­ 9­ On/Off­switch­(laser)
­ 10­ Adapter­(dust­extraction)
11 Parallel guide
­ 12­ Scale­(parallel­guide)
13 Case
­ 14­ Fixed­guard­cover
15 Screw
16 Flange
17 Saw blade
­ 18­ Guard­cover
­ 19­ Pull­lever­(guard­cover)
20 Guide rail
21 Chip ejector
22 Spindle lock
23 Cutting angle scale
24 Wing screws (cutting angle
scale)
25 Parallel guide holder
­ 26­ Wing­screw­(parallel­guide)
27 Charger
­ 28­ Release­button­(battery)
29 Rechargeable battery
­ 30­ Charge­level­indicator
31 Button
32 Laser labels

Functional description

The­cordless­circular­hand­saw­has­overlo-
ad protection, a spindle lock and a laser.
Please refer to the descriptions below for
information on how the operating elements
work.
