EN
22
INSTALLATION
Install the ductwork (for ducted hoods)
.
To reduce the risk of fire, use of metal ductwork is preferred.
chimney
hood
1.
Decide where the ductwork will run between the hood and the outside.
2.
A straight, short duct run will allow the hood to perform most efficiently while
using the extraction mode.
3.
Long duct runs, elbows, and transitions will reduce the performance of the
hood. Use as few of them as possible. Larger ducting may be required for best
performance with longer duct runs.
4.
The air must not be discharge into a flue that is used for exhausting fumes
from appliances burning gas or other fuels" "Regulations concerning the
discharge of air have to be fulfilled.
5.
Install wall cap. Connect round metal ductwork to cap and work back towards
hood location. Use duct tape to seal the joints between ductwork sections.
Electrical installation
Electrical wiring must be done by a qualified person(s) in accordance with all
applicable codes and standards. This range hood must be properly grounded.
Turn off electrical power at service entrance before wiring.
If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.
wall cap
round elbow
air outlet adapter
