8. CASCADE
The Cascade menu is only available if the System type Station 1 has been selected.
Main menu / Cascade
Adjustment
Description
channel
Threshold for activating the
Thresh. on
next station of the cascade
Threshold for deactivating the
Thresh. off station of the cascade that
has been activated at last.
Option Station 2 in the
Station 2
cascade
Option Station 3 in the
Station 3
cascade
Option Station 4 in the
Station 4
cascade
back
The parameter Thresh. on is used for adjusting the percentage of the maximum flow quantity
that has to be exceeded for switching on the next station. The parameter Thresh. off is used
for adjusting the percentage of the maximum flow quantity that has to be fallen below for swit-
ching off the station activated at last. In order to prevent a further station from being switched
on and off too often, reduce the value Thresh. off.
With the parameters Station 1 to Station 4 the number of stations in the cascade can be
adjusted.
In cascade operation, all adjustments have to be carried out at the cascade master (station
1). Stations 2 to 4 are cascade slaves and receive all information from the cascade master on
which all important adjustments have to be made. The menus are available for the slaves in an
shortened form.
Adjustment range /
Factory setting
selection
21 ... 100 % 90 %
10 ... 47 % 30 %
