Bergstrom COMPACT 3.0 Montageanweisungen Seite 19

COMPACT 3.0
Exploded view through to the attachment of the brackets
Aligner
Original edgeband
Cabin roof
Aligner
Upholstered
Ø8 Flat wide-flanged washer
Male-female hexagon
Exploded rear view to consoles fastening
Ø6 Rubber washer
Ø6 Flat wide-flanged washer
Male-male hexagon
Ø6 Flat washer
M6 Nut
Interior air distribution
6/100x15 Screw
panel
Ø8 Flat washer
Ø8 Flat washer
Console
19
Ø7 Rubber washer
Attachment bracket
M8/125 Screw
Male-male hexagon
6/100x15 Screw
EN
