nut. Drive the bearing up the taper the required distance. Use a dial indicator to monitor
the axial drive-up.
skf.com/mount & CD ROM MP3600 provide starting hydraulic pressure (MPa/psi) and axial
drive-up (mm) specifications.
Figure 10. One sliding surface
Figure 12. Two sliding surfaces
Zero Starting
position position
Figure 14. Bearing position
10
Figure 11. One sliding surface
Figure 13. Two sliding surfaces
Final
position
SKF HMV / HMVC
