13.1 Cleaning
• Keep protective devices, air vents and the motor
housing as free of dust and dirt as possible. Rub the
product clean with a clean cloth* or blow it off with
compressed air* at low pressure. We recommend that
you clean the product directly after every use.
• Never immerse the product in water or other liquids
for cleaning.
• Always keep the product clean, dry and free from oil
or grease. Remove dust after each use and before
storage.
• Do not use chemical, alkaline, abrasive or other ag-
gressive cleaning agents or disinfectants to clean the
product, as these may damage the surfaces.
13.1.1 Cleaning the reversible blade (Fig. 1)
1. Make sure that the reversible blades (12) are free of
residue.
This could impair the cutting properties of the revers-
ible blades.
Remove the residue with a graver* if necessary.
* = may not be included in the scope of delivery!
13.2 Maintenance
13.2.1 Turn and replace the lower reversible
blades (12) (Fig. 1, 4)
1. Place the product on its side.
2. Press and hold the locking button (9) to lock the cutter
head (10).
3. Open the fastening bolts (12a) of the reversible blades
(12) using the hexagon socket spanner (B).
4. Remove the reversible blade (12) and turn or replace
it. The individual cutting edges are numbered for bet-
ter orientation.
5. Ensure that all fastening screws (12a) are tightened
again.
13.2.2 Turn and replace the lateral reversible
blades (12) (Fig. 1, 4+5)
1. Place the product on a flat surface with the cutter
head (10) facing downwards.
2. Open the protective covers (8).
3. Press and hold the locking button (9) to lock the cutter
head (10).
4. Open the fastening bolts (12a) of the reversible blades
(12) using the hexagon socket spanner (B).
16 Troubleshooting
Fault
Motor does not start.
The motor runs slowly and does
not reach the operating speed.
20 | GB
Possible cause
On/off switch damaged
Damaged mains cable.
Voltage too low, coils dam-
aged, capacitor burnt.
www.scheppach.com
5. Remove the reversible blade (12) and turn or replace
it. The individual cutting edges are numbered for bet-
ter orientation.
6. Ensure that all fastening screws (12a) are tightened
again.
14 Storage
Store the product and its accessories in a dark, dry and
frost-free place that is inaccessible to children.
The optimum storage temperature is between 5°C and
30˚C.
Store the product in its original packaging.
Cover the product to protect it from dust or moisture.
Store the operating manual with the product.
15 Repair & ordering spare parts
After repairs or maintenance, make sure that all safety-re-
lated parts are installed and are in perfect condition. All
parts which may cause injury must be kept where they
are inaccessible to children or others.
ATTENTION
According to the German Product Liability Act, no liabili-
ty is accepted for damage caused by improper repairs
or by not using original spare parts.
Such work should be performed by a customer service
centre or an authorised specialists. The same applies to
accessory parts.
Connections and repairs
Connections and repair work on the electrical equipment
may only be carried out by electricians.
15.1 Ordering spare parts
Please provide the following information when ordering
spare parts:
• Model designation
• Item number
• Type plate data
Spare parts / accessories
Reversible blade set 4 pcs. -
Article number:
15.2 Service information
With this product, it is necessary to note that the following
parts are subject to natural or usage-related wear, or that
the following parts are required as consumables.
Wearing parts*: Abrasives, toothed belts
* = not included in the scope of delivery!
Remedy
Replace all damaged parts before you use your grind-
ing machine again. Contact your local service centre or
an authorised service station. Every attempt to carry
out a repair, can be dangerous if it is not done by
skilled personnel.
Have the voltage checked by a qualified electrician.
Arrange for inspection of the motor by a specialist. A
rrange for replacement of the capacitor by a specialist.
