1. INSTALLATION
GB
(Tab. A, B, C, pag. 8-10)
WELCOME TO THE CYCLONE WORLD.
Please read carefully this operating instruction manual to
get the best performances from your KOBRA Cyclone high
volume shredder.
INTRODUCTION
KOBRA CYCLONE is basically made by two single parts:
• The Cyclone + the shredding chamber
• The trolley, designed to move away the waste plastic
bag when full.
The machine is delivered packed in a sturdy wooden case
which protects the unit during transportation up to its
final destination [Fig.1].
The following tools are needed to unpack and install the
machine:
- Hammer
- Pincers
- 13 mm Wrench
- 4 mm Hexagon key
Open up the wooden case by removing the wooden cover
(2A) and wooden side walls (2B) by using your hammer
and pincers.
The Cyclone is now fixed and screwed to the wooden
pallet (2) [Fig.2] through the fixing plates (3-4).
Remove lateral (3) and rear (4) transportation plates by
loosing screws (1) and (3) [Fig.2].
Your Cyclone is now ready to move on the pallet. Before
sliding down the Cyclone off the pallet follow these steps
[Fig.3]:
o Open back doors (4) by opening the door lock (5).
o Release wooden ramps (3A) from the rear trolley (Q).
Align the ramps to the front of the pallet [Fig.4].
o Remove waste plastic bag trolley (Q) by pulling out the
two trolley fixing pins (7) [Fig. 3].
o Close back doors (4) and lock doors with door lock (5).
The Cyclone is now ready to leave the pallet.
suggested that at least two people take care of this
operation.
Open up completely the entry opening cover (7).
Grab the front of the machine as shown in [Fig.5] and pull
the Cyclone down off the pallet.
The second person should help the first operator from the
rear of the machine in pushing and keeping the Cyclone
aligned while it slides down off the pallet.
KOBRA Cyclone
The Cyclone is caster mounted and once it has reached the
floor level can be easily moved into its final destination.
The Cyclone dimensions are (LXWXH) 2120x800x2100
mm (85X32X84 inch) and the minimum dimensions of
the room for the Cyclone which allow a comfortable
operation of the machine are (LxWxH) 4000x2800x2500
mm (155X110x98inch).
The Cyclone should be postioned on a flat floor with the
four wheels firmly touching the floor.
The electrical installation of the Cyclone must be
performed by experienced electrical people which should
connect the electrical three phase line of your power
supply to the machine by complying to the electrical
safety standards required by the law in your country.
The Cyclone is delivered completely wired and including
the main power supply cord.
The power supply cord is 3 meters (10 Ft) in lenght with
3 wires + neutral wire + ground wire for 380-400Volts
connection or 3 wires + grounding conductor for
200-208Volts connection (USA-CANADA-JAPAN).
It is required to connect the main power cord wire to an
electrical terminal which is approved and complies with
the safety standards required by the law in the country of
installation.
If a longer wire is needed,replace the standard power cord
wire with a longer wire by disconnecting and reconnecting
the longer wire directly to the connector in the panel
board (see enclosed electrical diagram).
WARNING: DO
CONJUNCTION TO EXTEND THE LENGHT OF THE
STANDARD POWER SUPPLY CORD DELIVERED WITH THE
MACHINE. REPLACE THE WHOLE POWER CORD WIRE.
NOTE
1 - Electrical plugs or junction boxes must be located
It is
near the equipment and must be of easy access.
2 - To protect against excessive current, short circuit and
earth faults in PRIMARY CIRCUITS protective devices
must be integral part of the building installation.
