Read all the information provided in Section 7.1 before proceeding with any maintenance jobs.
t
igHtening tHe belt
Open the side panel to gain access to inside the compressor.
Every 500 hours of use it is advisable to check and maybe ti-
ghten the belt if necessary.
Using a dynamo meter apply a perpendicular force in point A of
between 25N and 35N, the belt must give by roughly 5mm.
Turn the nut 1 to tighten the belt.
Apply max 40 N of force. An excessive force could be damage
the paraoil and the screw unit!
r
.
eplacing tHe belt
Turn the nut 1 to slacken the belt.
Slide the belt out, replace it with a new one and tighten as descri-
bed in the previous section.
d
raining tHe condensate
Drain the condensate from the air tank at least once a month by
opening tap 1 secured to the foot of the tank.
The condensate drained is considered as polluting mix that
must not be thrown away outdoors. It is advisable to use special
water/oil separators for its disposal.
c
/
leaning tHe air
oil radiator
It is advisable to clean the radiator 1 on a weekly basis to remove
impurities, blowing it with an air gun from inside.
low compressed air through the radiator, from inside outwards,
making sure that no dirt settles inside the compressor
e
lectric motor maintenance
The bearings of the electric motor are already lubricated and are maintenance free.
In normal surrounding conditions (ambient temperature up to 30°C) replace the motor bearings every 12500 hours of use. In more
severe surrounding conditions (ambient temperature up to 40°C) replace the motor bearings every 8000 hours of use.
The bearings are to be replaced in any event every 4 years at the most.
Attention!
Before replacing the motor bearings, contact our customer service department, as established by the maintenance schedule.
7 . c
ompressor maintenance
22
F
(25/35 N)
A
5 mm
1
1
