ANHANG
Table 349: Example1: sMN ActivateEvaluationGroup – Deactivate evaluation group 1
<STX>sMN{SPC}ActivateEvaluationGroup{SPC}1{SPC}1{SPC}0<ETX>
<STX>sMN ActivateEvaluationGroup 1 1 0<ETX>
CoLa A
sMN ActivateEvaluationGroup 1 1 0
02 73 4D 4E 20 41 63 74 69 76 61 74 65 45 76 61 6C 75 61 74 69 6F 6E 47 72 6F 75 70 20 31 20 31
20 30 03
02 02 02 02 00 00 00 21
70 20 00 01 00 01 00
CoLa B
73 4D 4E 20 41 63 74 69 76 61 74 65 45 76 61 6C 75 61 74 69 6F 6E 47 72 6F 75 70 20 00 01 00 01
00
Table 350: Example2: sMN ActivateEvaluationGroup – Deactivate evaluation group 1, activate evaluation group 2 and 3
<STX>sMN{SPC}ActivateEvaluationGroup{SPC}3{SPC}1{SPC}0{SPC}2{SPC}1{SPC}3{SPC}1<ETX>
<STX>sMN ActivateEvaluationGroup 3 1 0 2 1 3 1<ETX>
CoLa A
sMN ActivateEvaluationGroup 3 1 0 2 1 3 1
02 73 4D 4E 20 41 63 74 69 76 61 74 65 45 76 61 6C 75 61 74 69 6F 6E 47 72 6F 75 70 20 33 20 31
20 30 20 32 20 31 20 33 20 31 03
02 02 02 02 00 00 00 21
70 20 00 03 00 01 00 00 02 01 00 03 01
CoLa B
73 4D 4E 20 41 63 74 69 76 61 74 65 45 76 61 6C 75 61 74 69 6F 6E 47 72 6F 75 70 20 00 03 00 01
00 00 02 01 00 03 01
Table 351: Telegram structure: sAN ActivateEvaluation
Telegram structure: sAN ActivateEvaluation
Telegram Description
part
Command Answer
type
Command Activate / deactivate
evaluation group
Amount of -
activated/
deacti‐
vated eval‐
uation
groups
State of -
activa‐
tion /
deactiva‐
tion
Table 352: Example 1: sAN ActivateEvaluation – Successfully deactivated evaluation group 1
<STX>sAN{SPC}ActivateEvaluation{SPC}1{SPC}1<ETX>
CoLa A
02 73 41 4E 20 41 63 74 69 76 61 74 65 45 76 61 6C 75 61 74 69 6F 6E 47 72 6F 75 70
02 02 02 02 00 00 00 1F
CoLa B
70 20 00 01 01 2C
166 B E T R I E B S A N L E I T U N G | multiScan165
73 4D 4E 20 41 63 74 69 76 61 74 65 45 76 61 6C 75 61 74 69 6F 6E 47 72 6F 75
20
73 4D 4E 20 41 63 74 69 76 61 74 65 45 76 61 6C 75 61 74 69 6F 6E 47 72 6F 75
23
Variable Length Additional details
String 3
String 23
UInt_16 2
Bool_1 1 Activation/Deactivation failed:
Successfully activated/deacti‐
vated:
73 41 4E 20 41 63 74 69 76 61 74 65 45 76 61 6C 75 61 74 69 6F 6E 47 72 6F 75
Values CoLa A Values CoLa B
(ASCII) (Binary)
sAN 73 52 41
ActivateEvalua‐ 41 63 74 69
tionGroup 76 61 74 65
45 76 61 6C
75 61 74 69 6F
6E 47 72 6F 75
70
1h... 30h 00 01 ... 00 30
0 00
1 01
20 31 20 31 03
