Result
BAD CELL
QR code in test result
˜ Cranking test
(Fig. C)
WARNING! Risk of injury! Firmly
m
engage the parking brake. Put the
vehicle in neutral transmission.
INFO:
Switch off the vehicle engine and all
o
other accessory loads before testing.
Otherwise the test results are not
accurate.
Do not stop the vehicle engine during
o
the cranking test.
Before testing: Connect the clamps to
o
the vehicle battery (see "Connecting
the clamps").
˜ Selecting the cranking test
1. Select Cranking Test.
2. Confirm the selection.
˜ Selecting the battery
voltage
1. Select the battery voltage.
2. Confirm the selection.
INFO: The screen of the product may vary in different EU countries.
40 GB/IE
Details
There has been a problem with a bad cell inside the
battery. The battery needs to be replaced.
1. Display the QR code: Press
2. Scan the QR code with a mobile phone.
˜ Conducting the cranking
test
INFO: If the engine is not started, the
cranking test can not be continued.
1. Follow the prompts to start the vehicle
engine.
The display
please wait.
The display
including:
–
–
–
, OK
[ 2 ]
shows Processing,
1 ] [
shows the test results
1 ] [
start-up duration
start-up status
start-up voltage
or .
4 ] [ 5 ] [
