Operating Instructions

3.1

Appliance overview

EN
Fig. 1a: Appliance overview, base (Fig. depends on model)
Fig. 1b: Appliance overview, heating head
FIN_103030102_DE-GB_HIT 2000-1 W Basic.indd 29
No. Designation
1 Supporting feet
2 Vertical pipe
3 Fastening nut
4 Metal rod (height adjustable)
5 Accessories: Fastening for heating
head (not shown)
No. Designation
1 Thermostat rotary knob
2 Heating element
3 Fastening bracket
4 Power cord
5 Protective mesh
6 Accessories: Fastening for heating
head (not shown)
