DISPLAY
The LED display shows the current operating mode and other system settings. The display disappears after 70 seconds of inactivity and is
re-activated as soon as one of the four keys MODE, ENTER, UP or DOWN is pressed.
6
OPERATING KEYS
MODE Select standalone functions, DMX mode and DMX address, slave mode and device settings.
ENTER Enter values and confirm changes.
Use the UP and DOWN keys to change brightness, stroboscope speed and DMX address.

OPERATION

NOTE
A few seconds after connecting the spotlight correctly to the mains it is ready for operation and the previously selected operating mode is activated.
INDIVIDUAL COLOUR TEMPERATURE
In order to set an individual colour temperature by mixing cold white and warm white and to create a preferred stroboscope effect, press
MODE repeatedly until "C" appears on the display and then press ENTER. Now use UP and DOWN to select "Cuxx" (cold white), "uuxx"
(warm white) or "CFxx" (stroboscope) and press ENTER to set the value, according to preference, between 00 and 99 using UP and DOWN
(CF00 = stroboscope deactivated, CF01 = slowest and CF99 = fastest stroboscope speed). Confirm your entry by pressing ENTER.
-
COLOUR TEMPERATURE PRESETS
In order to select one of the 15 colour temperature presets and set the brightness and stroboscope effect according to preference, press
MODE repeatedly until "Pr" appears on the display and then press ENTER. Now use UP and DOWN to select "Prxx" (Preset 1–15), confirm
by pressing ENTER and select a preset according to preference (preset 01 = cold white, preset 15 = warm white). Confirm by pressing
ENTER. Now use UP and DOWN once again to select "Pdxx" (dimmer) or "PFxx" (stroboscope) and press ENTER to set the value, according
to preference, between 00 and 99 using UP and DOWN (PF00 = stroboscope deactivated, PF01 = slowest and PF99 = fastest stroboscope
speed). Confirm your entry by pressing ENTER.
-
DIMMER RESPONSE
Use this menu item to set how the spotlight responds to changes in the DMX value in the dimmer channel. Press MODE repeatedly until
"drES" (Dimmer Response) is displayed and then press ENTER twice. Now set as desired using UP and DOWN. Confirm your entry by
pressing ENTER.
LEd = The spotlight responds abruptly to changes in the DMS value.
hALo = The spotlight responds like a halogen lamp, with gentle changes in brightness.
