5 Specifications

Data From Memory

Maximum reading rate out of memory
(Sample count 50000, trigger count 1, "FETC?" or "R?")
Readings
ASCII
4–byte Binary
8–byte Binary

General Specifications

Power Supply:
Power Line Frequency:
Power Consumption:
Operating Environment:
Storage Temperature
Operating Altitude
Rack Dimensions (WxHxD):212.8mm x 88.3mm x 272.3mm
Bench Dimensions (WxHxD):261.2mm x 103.8mm x 303.2mm
Weight:
Safety:
EMC:
Acoustic Noise
Display:
State Storage Memory
Remote Interfaces
154
GPIB USB 2.0
rdg/Sec rdg/Sec
4000 8500
89,000 265,000
47,000 154,000
100V/120V/ 220V / 240V ± 10%
50–60 Hz ± 10%,
400 Hz ± 10%.
Automatically sensed at power–on, 400 Hz defaults to 50Hz.
25 VA peak ( 16 W average )
Full accuracy for 0 °C to 55 °C
Full accuracy to 80% R.H. at 40
–40 °C to 70 °C
Up to 3000m
3.72 kg (8.2 lbs)
IEC 61010-1
EN 61010-1
UL 61010-1
CAN/CSA-C22.2 No. 61010-1
Refer to Declaration of Conformity for current revisions.
Measurement CAT II 300V, CAT I 1000V
Pollution Degree 2
IEC 61326
EN 61326
CISPR 11
ICES-001
AS/NZS 2064.1
Refer to Declaration of Conformity for current revisions.
37 dBa
Dual–line, 17–segment vacuum florescent display
Power Off state automatically saved, 4 User Configurable Stored States
GPIB IEEE–488, 10/100Mbit LAN, USB 2.0 Standard
LAN (VXI-11) LAN (Sockets)
rgs/Sec rdg/Sec
7000
110,000 270,000
60,000 160,000
o
C Non–condensing
34410A/11A User's Guide
8500
