SETTING INTO OPERATION

Making the Connections

1
Fix the control unit at a suitable place with two screws.
2
To control LED strips connect them to the terminals OUTPUT
3
To control light effects connect the XLR jack DMX OUT to the DMX
input of the first fixture. Connect the fixture's DMX output to the DMX
input of the following fixture etc., until all fixtures are connected in one
chain. Connect a 120 Ω terminating plug to the DMX output of the last
DMX unit in the chain.
4
For control via Art-Net, connect one of the node's RJ45 ports to a
computer network. Either via an Ethernet switch or directly to a PC or
notebook. Use a standard network cable (min. Cat 5). Both RJ45 ports
can be used as inputs and outputs as desired. A maximum of 50 nodes
can be connected in series. A maximum of 100 nodes can be used
when connected to two separate ports of an Ethernet switch.
Available number of pixels in Art-Net mode (per node)
LED strip
RGB light effect
RGBA or RGBW light effect
5
For control via a lighting controller with DMX512 protocol, connect the
controller to the XLR jack DMX IN.
Available number of pixels in DMX mode (per node)
LED strip
6
Connect the power supply unit provided to the power input DC IN on the
device and to a mains socket (100-240 V~, 50/60 Hz). Thus the node is
powered on. By disconnecting the unit from the mains it can be
switched off.
www.eurolite.de
19
170
170
128
170
