DMX Settings

1
To control light effects set them to DMX mode. RGB fixtures must be
equipped with DMX channels for controlling red, green and blue LEDs.
RGBA or RGBW fixtures must be equipped with DMX channels for
controlling red, green, blue, amber or white LEDs.
2
The DMX channel mode depends on the number of pixels the fixtures
have.
Example 1: If an RGB fixture has 6 pixels, it must be set 18-channel
mode with the following DMX protocol:
Channel
1
2
3
V
16
17
18
Example 2: If an RGBA fixture has 6 pixels, it must be set 24-channel
mode with the following DMX protocol:
Channel
1
2
3
4
V
21
22
23
24
3
The start address of the first fixture connected to the node must be set
to 1. The start addresses of the following units depend on the number of
DMX channels each unit occupies. For example, if each fixture occupies
20 channel, set the first unit to 1 and the following units to a multiple of 1
(21, 41, 61 etc.).
www.eurolite.de
DMX value Function
0-255 Red 1 dark
0-255 Green 1 dark
0-255 Blue 1 dark
V V
0-255 Red 6 dark
0-255 Green 6 dark
0-255 Blue 6 dark
DMX value Function
0-255 Red 1 dark
0-255 Green 1 dark
0-255 Blue 1 dark
0-255 Amber 1 dark
V V
0-255 Red 6 dark
0-255 Green 6 dark
0-255 Blue 6 dark
0-255 Amber 6 dark
20
bright
bright
bright
bright
bright
bright
bright
bright
bright
bright
bright
bright
bright
bright
