Menu

Button Function
MENU Calls the menu and the next menu item.
ENTER Selects the submenu
▲ Increases values when modifying
▼ Decreases values when modifying
MENU ENTER
DMX mode
LED Tape -
Color mode
Manual Red
Green
Blue
Flash
Automatic mode
Prog Run Value
Speed
Flash
Art-Net mode
Artnet Out
Out
IP0
IP1
IP2
IP3
SW0
SW1
SW2
SW3
U1
System settings
Option BLGT
BLGT
BRCO
SYSRESET
www.eurolite.de
▲/▼ Function
0-170 Number of pixels to be controlled
0-255 Brightness red
0-255 Brightness green
0-255 Brightness blue
0-15 Flash speed
1-16 Selects a light program
0-15 Program running speed
0-15 Program flash speed
Tape For controlling LED strips
DMX For controlling light effects
0-255 Input the IP address section 1
0-255 Input the IP address section 2
0-255 Input the IP address section 3
0-255 Input the IP address section 4
0-255 Input the subnet part section 1
0-255 Input the subnet part section 2
0-255 Input the subnet part section 3
0-255 Input the subnet part section 4
1-32768 Input the DMX universe number
ON Display backlight always on
OFF Display backlight off after 20 sec
0-100 Display brightness
ON Reset unit to factory settings (press
buttons ▲ and ▼ to start reset)
