Overview
1 Front cover (transparent)
2 Star-shaped screw with
domed nut
3 Dosing head
4 Suction and pressure con-
nector
5 Rotor
6
Roller
7 Hose
not shown
Hose rupture sensor
1 2
6 5 7
LED indicators
Fault indicator [10] Fault message
Warning indicator [11] Warning message
Operating indicator [12] The pump is now ready for
operation.
The LED flashes depending on
the dosing rate.
3 4
4
Control unit
10 11 12
1
2
XX.X
3
L/h
4
XXXX cp
5
6
7
1 LCD screen
2 Status display
3
Main display
4 Secondary display
5 [Back] key
6 Clickwheel
7 [STOP/START] key
8 [Menu] key
9 [Priming] key
8
9
